ALUMINUM OUTDOOR DOORS
MasterLine 10
The MasterLine 10 is a versatile and energy-efficient door system from “Reynaers Aluminium”, designed to meet the demands of modern architecture. This system offers exceptional thermal insulation, making it ideal for low-energy and passive buildings.
With its slim sightlines and various configurations, including fixed and opening elements, MasterLine 10 provides a sleek aesthetic that enhances natural light and visibility. The system is available in different styles, including inward and outward opening options, and supports a wide range of glazing thicknesses. Additionally, MasterLine 10 meets high security standards and offers excellent weather performance, ensuring durability and comfort in any setting.
| MasterLine 10 Technical parameters | |
|---|---|
| Thermal insulation: | Uf value from 0,99 W/m2K depending on the choice of frame/sash and glass thickness |
| Acoustics: | Rw(C;Ctr) = 46 (-1;-4) dB, depending on the type of glazing |
| Air tightness: | up to 600 Pa (Class 4) |
| Wind load resistance: | up to 1600 Pa (Class C4) |
| Water tightness: | up to 900 Pa (E900 class) |
| Burglar resistance: | up to RC2-RC3 |
