MasterPatio
MasterPatio is an innovative lift-slide door system designed to combine maximum functionality and user comfort with modern aesthetics.The system offers unlimited design flexibility, and its excellent thermal performance makes it ideal for low-energy and passive buildings.With its high durability, MasterPatio is also a perfect choice for high-rise buildings.A key feature of the system is its minimalist design, seamlessly blending into various architectural styles.
Slim profiles and multiple configuration options create a sense of lightness, allowing users to enjoy beautiful views and a feeling of unlimited space. MasterPatio lift-slide doors can be combined with MasterLine 8 windows and doors, ensuring a cohesive, aesthetic appearance. Additional solutions, such as a glass or openable corner, low or hidden threshold, or pocket solution, are also available. The system can be integrated with smart home technology, offering various control options.
The integrated Flyscreen mosquito net is an innovative addition, enhancing user comfort by protecting against insects while harmonizing with the minimalist style of MasterPatio.
| MasterPatio Technical parameters | |
|---|---|
| Thermal insulation : | Uf value from 0,8 W/m2K depending on the choice of frame/sash and glass thickness |
| Acoustics: | Rw(C;Ctr) = 44 (-1;-4) dB, depending onthe type of glazing |
| Air tightness: | up to 600 Pa (Class 4) |
| Wind load resistance: | up to 2000 Pa (Class E1200 |
| Water tightness: | up to 1200 Pa (Class E1200) |
| Burglar resistance: | up to PAS 24 - RC2 |
